A1.  機殼型電源館

館長：林簡松  Rex      rex.lin@meanwell.com

(02) 2299-6100 #618

產品介紹
最新產品
影音專區
解決方案

產品介紹

產品藍圖

       欲瞭解更多新品資訊及開發中產品，請點擊下方連結。



產品藍圖下載 (PDF)
鉛酸電池介紹 (.html)

最新產品

SHP-30K系列

30KW 三相三線式超高瓦數工業級標準電源

MEAN WELL SHP-30K Series, 30KW 3 Phase 3 Wire High Efficiency Digital Power Supply

        SHP-30K 系列為目前全球最高瓦數的單體 30KW 高功率 AC/DC 標準電源供應器，輸入電壓 AC 三相三線式，DC 輸出則提供了包含符合低壓 55V (<60V SELV)及高壓(HVDC)輸出的 115V/ 230V/ 380V 等四種標準機型；特別適用於各類新能源與先進工業應用領域，如：儲能櫃、儲能牆、氫能、風能與太陽能、EV 電動車 DC 快速充電系統等相關應用，工業 IT 大數據伺服器與機房不斷電 UPS 系統電源，5G 基地台及各類網通系統...

HRPG-1000N3系列

1000W 320% 峰值功率機殼型電源

MEAN WELL HRPG-1000N3 Series, 1000W Enclosed Type Power Supply with 320% Peak Power

        本次新增具 320% 峰值功率機殼型 HRPG-1000N3 系列，提供客戶更高瓦特數的使用需求；機殼型應用的產業領域廣泛，包含各種電機設備或電子控制使用。當搭配電感性負載像是馬達類產品時，在開機瞬間就需要提供較高的開機功率，或在搭配電子控制線路時則會有較多的儲能電容以致開機瞬間也會有大電流的電容性負載應用。因此，明緯全新 HRP(G)-150/ 300/ 600/ 1000N3 系列，主要協助客戶在不需要加大電源瓦數情況下...

LRS-N2系列

100W~600W
200%峰值功率機殼型電源

MEAN WELL LRS-N2 Series, 100W~600W Enclosed Type Power Supply with 200% Peak Power

        本次新上市的 LRS-100/200/350/600 N2 產品，與舊款 LRS 系列最大的差異在於增加可達 5 秒 200% 瞬間峰值功率的設計；減少客戶搭配各種瞬間大電流啟動應用問題，客戶不需購買較高瓦數來使用，而是可搭配正常功率結合有瞬間峰值功率的電源來使用，降低電源採購成本及協助客戶改善應用問題。同時輸出電壓也提供以工業設備常用電壓 12V/24V/36V/48V 等機型為主...



影音專區

30KW三相三線30K瓦高效率電源供應器— SHP-30K系列

      SHP-30K為交流三相輸入轉高壓直流電源供應器，輸出電壓可分55VDC、115VDC、230VDC、380VDC，產品為2U高度設計，適合通訊、半導體、食品加工、工業自動化等設備應用。



了解更多


2200W能源回饋式雙向交直流電源供應器— BIC-2200系列

      明緯BIC-2200雙向電源，對於電動車充電設備、電池測試和其他儲能系統不斷增長的需求，它都能保持最高效率以降低營運成本，是您絕佳的電源選擇。



了解更多


7500W三相四線直流高壓輸出電源— RST-7K5系列

     明緯RST-7K5高壓輸出電源，在輸出電壓應用提供115V、230V及380V三種機型，可提供不同產業應用，如工業設備、充電儲能系統、電解設備、集中供電…等。此外，RST-7K5提供兩種不同散熱方式供客戶選用，分別是內建風扇的強制風冷型(RST-7K5/15K)，與搭配水冷板的水冷型(RST-7K5L)，使用者可依據設備特性或現場環境選擇合適的散熱方式。



了解更多


解決方案

MEAN WELL CMU2 and ERG-5000H series, Burn-in system

MEAN WELL UHP-500-48 series and HLG-480 series, outdoor mobile cooling system

MEAN WELL UHP-1000 series, RCP-2000 series and RKP-CMU1 series

As an expansion of the previous SHP-10K series, the SHP-30K not only meets the customer demands by increasing the wattage but also improves the output parallel function up to >300KW, provides complete programmable output voltage (PV) and current (PC) control functions, built-in CAN Bus communication protocol (optional PMBus or Modbus); it also provides OLP/OTP/OVP protections, DC-OK/Fan Failure/AC Failure/Over Temperature Alarm signals, and 12V DC auxiliary power.

The HRP (G) series is positioned as a high-end enclosed-type industrial power supply, designed with a double-sided layout PCB and provides a variety of control functions: such as DC OK/Remote ON-OFF/Remote Sense and parallel functions (>600W). The double-sided PCB layout offers stable quality in harsh vibration or high ambient temperature applications for the industrial field, related monitoring functions can be used in combination with human-machine interface and automation control. In addition, MEAN WELL also provides HRP(G)-N3 series products with >300% peak power, which can be used with inductive loads or capacitive loads that require peak power, providing customers with a complete solution for standard industrial power supply.

The enclosed-type is one of the major product lines, MEAN WELL also continues to develop new products to provide more standardized power supplies to serve global customers and various industrial applications. The biggest difference between the newly-launched LRS-100/200/350/600 N2 series and the previous LRS is providing instant 200% peak power for up to 5 seconds, which reduces the issues when matching with various instantaneous high current during startup applications. Customers don't need to buy higher wattage, simply use it with a normal wattage that combined with instantaneous peak power. By doing so, this can not only reduce the purchasing cost of power supply but also help customers to improve application problems. The output voltage provided this time are 12V/24V/36V/48V models, which are commonly used in industrial equipment. The other mechanical dimensions are the same as the previous LRS series, making it convenient for customers to replace them.

The NCP-3200 series provides 3 output voltage models, including low-voltage SELV-compliant DC 24VDC/ 48VDC and high-voltage DC 380VDC, which can be used in a wide variety of power electronics, communication industries and energy systems' equipment.

In response to market needs, MEAN WELL's ERG-5000 series power inverter provides 2 types of input voltage models: Blank type (10~60 VDC) and H type (60~420 VDC). Customers can choose according to the production aging and energy recycling application requirements of different industries, such as battery testing equipment, charging energy storage systems, charging piles and others.

In recent years, due to the needs created by rapid urban development, the demand for safe, reliable, certified and smart security/ fire alarm power supplies has been increasing. Accordingly, MEAN WELL is announcing its new Enclosed Type Economical Security/ Fire Alarm Power Supply LAD-120/ 240/ 360/ 600 series.
